I’ll just go straight to the point. This simple tutorial will show you steps to properly install Qualcomm QDLoader drivers on Windows, either Windows 8, 8.1 or 10. You may need it in few occasions involving your MIUI device powered with any variant of Qualcomm chipset. As we know it that many of Xiaomi’s most popular phones like Mi5, Mi 5, Redmi Note 3, and so on, are powered with Qualcomm Snapdragon chipset. Any way, let’s just start the guide.
Which may be a hint that their driver actually sends touch data encoded as /tuio/2Dcur cursors. You could try to use one of the available TUIO client demos for any platform or language and see if you can receive anything on their UDP port (which seems to be different from the standard TUIO UDP port 3333). Android USB drivers are a necessary tool in your PC and Mac. They act as a bridge between your mobile device and your PC helping them to interact and communicate. The USB drivers help in connecting our phones to your computer and performing tasks like transferring photos and other data. Step 9 – Open up Device Manager from control panel and you will notice a new device is detected but its driver is not installed properly. Usually it is displayed as “QHSUSBBULK” under Other Devices. Step 10 – Right-click on QHSUSBBULK and choose “Update Driver Software“. Step 11 – A dialog window shall appear.
Also read : How to install MIUI 8 Developer ROM on Redmi Note 3.
- Download Qualcomm QDLoader Drivers package.
- Download ADB USB Drivers or Mi PC Suite.
- Download Minimal Fastboot files.
- Any MIUI device powered with Qualcomm Snapdragon.
- A USB cable.
- A computer running Windows 8, 8.1 or 10.
Step 0 – Extract the Qualcomm QDLoader .zip file using either Winzip or Winrar.
Step 1 – Install either ADB USB Drivers or Mi PC Suite only if you have not done it yet, otherwise you don’t have to. This is necessary to make sure your computer can recognize and communicate with your phone properly.
Step 2 – Extract Minimal Fastboot .zip file and go to the folder of where the extracted files are located (via Windows Explorer).
Step 3 – Enable Developer Options on your phone. Just go toSettings >>About phones >> tap on the MIUI Version 7 times. You can skip this step if you have it enabled previously.
Step 4 – Enable USB Debugging on your phone. Go to Settings >> Additional Settings >>Developer Options >> enable USB Debugging.
Step 5 – Now reboot your phone into Fastboot mode. In most cases, you can do it by pressing Volume Down (-) button and Power button simultaneously until Fastboot Bunny logo appeared.
Step 6 – Now connect your phone into your computer.
Step 7 – In Windows Explorer opening Minimal Fastboot Files folder, hold down / press the Shift button on your keyboard and right-click anywhere in the folder, and then choose “Open Command Window from Here” option.
Step 8 – Now type following command :
Your phone shall now reboot into EDL mode
Step 9 – Open up Device Manager from control panel and you will notice a new device is detected but its driver is not installed properly.
Usually it is displayed as “QHSUSB_BULK” under Other Devices.
Step 10 – Right-click on QHSUSB_BULK and choose “Update Driver Software“.
Step 11 – A dialog window shall appear. Choose “Browse my computer for driver software“.
Step 12 – Now click on the Browse button and locate the extracted Qualcomm QDLoader drivers.
Step 13 – The installation process shall take place immediately and a system notification will appear. Just choose “Install this driver software anyway“.
Step 14 – Once done, you will see something like this.
Step 15 – Click the Close button and check back at Device Manager window. You will now see “Qualcomm HS-USB QDLoader 9008 (COM10)” under Ports (COM & LPT) section.
Done! Congratulation, you have now installed Qualcomm HS-USB QDLoader successfully on your computer.
